Blue 60 Fire Rated Packers - 3x15x100mm - Pack of 100 - White

Blue 60 Fire Rated Packers - 3x15x100mm - Pack of 100 - White

$22.34
Blue 60 Fire Rated Packers - 3x15x100mm - Pack of 100 - White—
$22.34

The Story

Fire Rated Packers designed specifically for use with Blue 60 Fire Rated Foam are inserted around the door frame fixings to provide fire rated foam with an even surface during expansion and to help prevent foam from flowing out and onto the floor.

They provide up to 60 minute fire protection on timber doorsets without the use of additional mastics or sealants and are suitable for both timber and metal stud partitionings. They are available in three thicknesses which can be combined to achieve a proper fitting and are acoustically tested up to 43dB. In order to maintain fire rating certification, these Fire Rated Packers must be used with Blue 60 Fire Rated Foam.
  • Tested in full size single & double doorsets
  • Tested with softwood, MDF & hardwood frame sections
  • Tested with gaps between 7mm & 30mm
  • White in colour for compliance identification purposes

Ratio of Blue 60 Packers per tin of Blue 60 Foam

There are 10 fixing points per frame with the correct gaps of 7/9mm = 3 packers per fixing - 30 packers per frame.

One can of Blue 60 with correct gaps of 7/9mm is enough for 3 doorsets, equalling 90 packers per can plus extra packers for shimming under the frame to square the head due to uneven floor surfaces equates to 100 packers required per can.

If the gaps are bigger then more foam and packers are required on a pro-rata basis.

To summarise 33 of each size of packer is required per can of foam and there are 3 different sizes of packer.

Per box there are 4 bags x 100 of each size of packer are required.

Blue 60 Fire Rated Packers - 3x15x100mm - Pack of 100 - White - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

Fire Rated Packers designed specifically for use with Blue 60 Fire Rated Foam are inserted around the door frame fixings to provide fire rated foam with an even surface during expansion and to help prevent foam from flowing out and onto the floor.

They provide up to 60 minute fire protection on timber doorsets without the use of additional mastics or sealants and are suitable for both timber and metal stud partitionings. They are available in three thicknesses which can be combined to achieve a proper fitting and are acoustically tested up to 43dB. In order to maintain fire rating certification, these Fire Rated Packers must be used with Blue 60 Fire Rated Foam.
  • Tested in full size single & double doorsets
  • Tested with softwood, MDF & hardwood frame sections
  • Tested with gaps between 7mm & 30mm
  • White in colour for compliance identification purposes

Ratio of Blue 60 Packers per tin of Blue 60 Foam

There are 10 fixing points per frame with the correct gaps of 7/9mm = 3 packers per fixing - 30 packers per frame.

One can of Blue 60 with correct gaps of 7/9mm is enough for 3 doorsets, equalling 90 packers per can plus extra packers for shimming under the frame to square the head due to uneven floor surfaces equates to 100 packers required per can.

If the gaps are bigger then more foam and packers are required on a pro-rata basis.

To summarise 33 of each size of packer is required per can of foam and there are 3 different sizes of packer.

Per box there are 4 bags x 100 of each size of packer are required.
